Completely eliminate leakage, long service life, wide operating temperature range -40℃~+85℃.
|
|
model |
voltage |
capacity |
Size（mm） |
Storing energy |
ESR |
weight |
volume |
Outlet type |
Operating temperature range |
|
HCAP-D 5R5 474-F |
5.5V |
0.47F |
9.5x17.5x18 |
7.1J |
220mΩ |
3.4g |
2.6ml |
The needle |
-40~+70℃ |
|
HCAP-D 5R5 105-F |
5.5V |
1F |
9.5x17.5x18 |
15.1J |
180mΩ |
3.5g |
2.6ml |
The needle |
-40~+70℃ |
|
HCAP-D 5R5 155-F |
5.5V |
1.5F |
9.5x17.5x23 |
22.7J |
150mΩ |
4.3g |
3.4ml |
The needle |
-40~+70℃ |
|
HCAP-D 5R5 255-F |
5.5V |
2.5F |
11.5x22x23.5 |
37.8J |
120mΩ |
6.5g |
5.3ml |
The needle |
-40~+70℃ |
|
HCAP-D 5R5 505-F |
5.5V |
5F |
11.5x22x28.5 |
75.6J |
100mΩ |
8g |
6.4ml |
The needle |
-40~+70℃ |
|
Note: the above specifications are for reference only. The latest specifications of the company shall prevail. |
|||||||||
|
Communication module, power failure warning, meter RTC, concentrator,
More suitable for water, gas and other moisture-proof, waterproof characteristics of higher requirements, relatively sealed occasions.
|
