PRODUCTS

2.7V series small capacity monomer

Product features

Small capacity of monomer mainly refers to the ulcapacitors with rated voltage of 2.7v and capacity range of 1F-60F.

This type of supercapacitor has short charging time and good high and low temperature characteristics (-40℃~+70℃).

Super long service life, it is an ideal backup power supply for small current power supply such as clock chip and data transmission system.

Product technical parameters

model	voltage	capacity	Size （mm）	Storing energy	ESR	weight	volume	Outlet type	Operating temperature range
HCAP-S 2R7 105	2.7V	1F	φ6.3x12.5	3.6J	260mΩ	0.6g	0.4ml	The needle	-40~+70℃
HCAP-C 2R7 105A	2.7V	1F	φ8x12	3.6J	110mΩ	1g	0.6ml	The needle	-40~+70℃
HCAP-C 2R7 205B	2.7V	2F	φ8x15	7.3J	90mΩ	1.1g	0.75ml	The needle	-40~+70℃
HCAP-C 2R7 335	2.7V	3.3F	φ8x20	12J	75mΩ	1.4g	1ml	The needle	-40~+70℃
HCAP-C 2R7 505	2.7V	5F	φ10x20	18.2J	60mΩ	2.2g	1.6ml	The needle	-40~+70℃
HCAP-C 2R7 705	2.7V	7F	φ10x20	25.5J	60mΩ	2.2g	1.6ml	The needle	-40~+70℃
HCAP-C 2R7 106	2.7V	10F	φ10x25	36.5J	50mΩ	2.7g	2.0ml	The needle	-40~+70℃
HCAP-C 2R7 156	2.7V	15F	φ12.5x25	54.7J	50mΩ	4.2g	3.1ml	The needle	-40~+70℃
HCAP-C 2R7 166	2.7V	16F	φ16x20	58.3J	50mΩ	5.5g	4.0ml	The needle	-40~+70℃
HCAP-C 2R7 206	2.7V	20F	φ12.5x30	72.9J	45mΩ	5g	3.7ml	The needle	-40~+70℃
HCAP-C 2R7 256	2.7V	25F	φ16x25	91.1J	40mΩ	6.8g	5ml	The needle	-40~+70℃
HCAP-C 2R7 356	2.7V	35F	φ16x35	128J	30mΩ	9g	7ml	The needle	-40~+70℃
Note: the above specifications are for reference only. The latest specifications of the company shall prevail.
