PRODUCTS

2.7v series volume monomer

Product features

The capacity of monomer mainly refers to the ulcapacitors with rated voltage of 2.7v and capacity range of 60F-600F.

This type of super capacitor has high power discharge capacity, high and low temperature characteristics (-40℃~+70℃),?

short charging?time, long service life, environmental protection and other characteristics.

Product technical parameters

Intelligent distribution network (FTU/DTU/TTU/ fault indicator and other distribution network terminal equipment),

Military, automotive emergency start, aerospace, fan control system,?

UPS power supply, AGV, industrial electronics and transportation energy.

Product application

model	voltage	capacity	Size （mm）	Storing energy	ESR	weight	volume	Outlet type	Operating temperature range
HCAP-C 2R7 606 L	2.7V	60F	φ18x40	219J	25mΩ	13g	10ml	The needle	-40~+70℃
HCAP-C 2R7 107	2.7V	100F	φ22x45	365J	18mΩ	20g	17ml	horn	-40~+70℃
HCAP-C 2R7 127 S	2.7V	120F	φ22x50	437J	10mΩ	23g	19ml	horn	-40~+70℃
HCAP-C 2R7 227	2.7V	220F	φ30x50	802J	8mΩ	40g	35ml	horn	-40~+70℃
HCAP-C 2R7 247	2.7V	240F	φ30x50	875J	8mΩ	42g	35ml	horn	-40~+70℃
HCAP-C 2R7 277	2.7V	270F	φ30x50	984J	8mΩ	45g	35ml	horn	-40~+70℃
HCAP-C 2R7 337	2.7V	330F	φ30x60	1.2KJ	8mΩ	50g	42ml	horn	-40~+70℃
HCAP-C 2R7 407 S	2.7V	400F	φ35x60	1.46KJ	6mΩ	70g	58ml	horn	-40~+70℃
HCAP-C 2R7 407 M	2.7V	400F	φ35x64	1.46KJ	3mΩ	65g	62ml	stud	-40~+70℃
HCAP-C 2R7 477	2.7V	470F	φ35x60	1.7KJ	7mΩ	70g	58ml	horn	-40~+70℃
HCAP-C 2R7 607	2.7V	600F	φ35x72	2.2KJ	7mΩ	85g	69ml	horn	-40~+70℃
Note: the above specifications are for reference only. The latest specifications of the company shall prevail.
